Description

RG6 Coaxial Cable

Number of Conductors: 1
5-15mm dia for QS cable one hd
 BC/CCS/TC/CCA/CCC Conductor and so on for QS cable one hd
Insulation Foam PE/Solid PE for QS cable one hd
Al Foil / CU FOIL/ BLUE FOIL/ COPIED FOIL/ BONDED FOIL Shield and so on
Braiding: Al-Mg/CCA/BC/TC and so on for QS cable one hd
Jacket: PVC/PE/ RESIN AND SO ON for QS cable one hd
Application: CCTV/ CATV/ MATV/ ANTENNA/ SATELLITE and so on

RG6 Coaxial Cable has Coaxial Design: RG6 cable is designed with a coaxial construction, which consists of a central conductor, an insulating layer, a metallic shield, and an outer insulating jacket. This design provides excellent protection against electromagnetic interference (EMI) and signal loss.
RG6 Coaxial Cable has Applications: RG6 cables are commonly used for a variety of applications, including cable television (CATV), satellite TV, over-the-air (OTA) broadcasts, high-speed internet (broadband), and security camera installations. They are suitable for both residential and commercial use.
RG6 Coaxial Cable has Frequency Range: RG6 cables are capable of transmitting a wide range of frequencies, making them suitable for high-frequency applications. They are often used for signals in the RF (Radio Frequency) spectrum.
RG6 Coaxial Cable has Impedance: RG6 cables typically have an impedance of 75 ohms, which is the standard impedance for many audio and video applications. This impedance matches the impedance of most consumer electronics, ensuring efficient signal transmission.
RG6 Coaxial Cable has Center Conductor: The central conductor is typically made of copper or copper-clad steel (CCS). Copper conductors offer excellent signal conductivity, while CCS provides a cost-effective alternative.
RG6 Coaxial Cable has Dielectric Insulation: The central conductor is surrounded by a dielectric insulating material, which helps maintain the signal’s integrity by preventing signal leakage and interference.
RG6 Coaxial Cable has Aluminum or Copper Shielding: RG6 cables have a metallic shield layer to protect against EMI and maintain signal quality. The shield can be made of aluminum or copper, with copper being more effective in shielding against interference.
RG6 Coaxial Cable has Outer Insulating Jacket: The cable is encased in an outer insulating jacket, which provides physical protection and RG6 Coaxial Cable has durability. This jacket is typically made of PVC (Polyvinyl Chloride) or similar materials.
RG6 Coaxial Cable has Weather Resistance: Some RG6 cables are designed for outdoor use and are weather-resistant. These outdoor-rated cables are equipped with additional features such as UV resistance and moisture protection.
RG6 Coaxial Cable has Connectors: RG6 cables are commonly terminated with F-type connectors, which are the standard connectors for coaxial cables in audio and video applications. These connectors provide a secure and reliable connection.
Available Lengths: RG6 cables are available in various lengths to accommodate different installation needs, from short indoor runs to long outdoor installations.
Color: RG6 cables typically come in various colors, with black and white being the most common choices. The color is often chosen based on aesthetic preferences or to match the installation environment.
Performance: RG6 cables are known for their excellent performance in maintaining signal quality over long distances, making them ideal for long cable runs in television and data transmission.
