Description

Hikvision DS-3E0109P-E/M(B) 8 ports 100Mbps Unmanaged PoE Switch - DS-3E0109P-E/M(B)

8 × 100 Mbps PoE ports, 1 × 100 Mbps Ethernet port
RJ45 port, full duplex, MDI/MDI-X adaptive
Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
High priority ports: Ports 1 to 2
Ports for Long-Distance: Ports 1 to 8
Switching Capacity: 1.8 Gbps
Packet Forwarding Rate: 1.339 Mpps
PoE Standard: IEEE 802.3af, IEEE 802.3at
PoE Power Pin: Supports 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply
Maximum Power Consumption: 65 Watts
PoE Power Pudget: 60 Watts
Maximum Port Power: 30 Watts
Metal material, fan-free design

Hikvision DS-3E0109P-E/M(B) 8 ports 100Mbps Unmanaged PoE Switch
DS-3E0109P-E/M(B) is a layer 2 100M PoE switch. Based on wire speed forwarding, the switch supports Ethernet PoE power supply and extend mode. The power supply distance reaches as long as 250 m. It also supports prior and stable transmission of the important surveillance area video when connected to the high priority ports.

Hikvision DS-3E0109P-E/M(B) has Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
Hikvision DS-3E0109P-E/M(B) has Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
Hikvision DS-3E0109P-E/M(B) has 4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
Hikvision DS-3E0109P-E/M(B) has 6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.

Hikvision DS-3E0109P-E/M(B) has PoE Capability: With Power over Ethernet capability, the switch can deliver both power and data over a single Ethernet cable, simplifying installation and reducing the need for additional power outlets or wiring.
Hikvision DS-3E0109P-E/M(B) is Unmanaged: Hikvision DS-3E0109P-E/M(B) is unmanaged, meaning it operates as a plug-and-play device without the need for configuration. This makes it suitable for simple network setups where advanced features are not required.
Hikvision DS-3E0109P-E/M(B) has Compact Design: The DS-3E0109P-E/M(B) features a compact and sturdy design, making it suitable for desktop or wall mounting, providing flexibility in installation.
Hikvision DS-3E0109P-E/M(B) has IEEE Standards: Hikvision DS-3E0109P-E/M(B) adheres to IEEE standards for networking and PoE, ensuring compatibility with a wide range of devices and network equipment.
Hikvision DS-3E0109P-E/M(B) has Data Transfer: Along with power delivery, the switch also provides high-speed data transfer rates over Ethernet, enabling smooth and reliable communication within the network.
