Hikvision Non- touch Exit & Emergency Button

Hikvision Non- touch Exit & Emergency Button - DS-K7P03

Stock Status: Available In Stock

Condition: New

SKU : 1346M24

KES 2,500

Key Features

Hikvision Non- touch Exit & Emergency Button - DS-K7P03

New version of DS-K7P03, there is "/T" in the label
Stainless steel panel, Led Indicator
Dimension(L×W×H): 86×86×25.7mm(3.39×3.39×1.01"
Current Rating; 1 A@30 VDC
Output Contact; NO/NC/COM contact
Suitable Doors; All kinds of narrow doorframes

Warranty (12 months)

The warranty tendered hereunder, on the electronic product(s) sold under this invoice will be provided exclusively by their respective Authorized Agents/Distributors and are limited to the period indicated from the date ofyour invoice, except otherwise mentioned as per the warranty conditions as carried along with the products(s)
Warranty Guide

Seen it cheaper?

ASK FOR A elevenshops.com DEAL

Chat with us Call 254728666222

Description

Hikvision Non- touch Exit & Emergency Button - DS-K7P03

The Hikvision DS-K7P03 is a touch free door exit & emergency button for access controlled doorways where non contact is important, such as schools, laboratories and hospitals.

The contactless sensor is embedded in a stainless steel face plate and is illuminated with white/green/red LED indication lights and the low profile casing is ideal for narrow doorway.

The relay opening times can be adjusted between 0.5 to 20 seconds so the DS-K7P03 can be mounted further away from the door than conventional door exit buttons.

Hikvision DS-K7P03 Features:

Dimension (L x W x H) 86 x 86 x 25.7mm (3.39″ x 3.39 x 1.01″)
Input voltage: 12V DC
Working current: 40 mA (standby), 70mA (working)
Current rating: 1 A@30 VDC
Output contact: NO/NC/COM contact
Panel: Stainless steel
Aging test: Already passed 1 million times aging test
Suitable doors: All kinds of narrow doorframes
Working Temperature: -20ºC to 50ºC (-4ºF to 122ºF)
Working humidity: 0 to 95% (relative humidity)
Detection range (adjustable): 40mm to 120mm (1.57 to 4.72″)
Time delay: 1 to 25s (adjustable)
LED indicator status: Green/red LED indicates working/standby
Product weight: 0.2kg (0.44lb)
